Economical, budget-friendly and very easy to maintain – Elegance series is an efficient model using a sleek aluminium anodized and Nylon Polyamide hardware, apart from standard black. It is also offered in grey, off-white and white finishes
CAD File on request
The Elegance Box-Up Series by Super Creations introduces an innovative and stylish solution to restroom cubicles, combining an extra layer of privacy with the robust elegance developed in response to customer demand, these cubicles feature a bottom stainless steel box that delivers an enclosed and clean aesthetic. Ideal for settings such as hostels, dormitories, colleges, swimming pools, showers, and change rooms, the Elegance Box-Up Series is a versatile and reliable choice for those seeking both privacy and durability.
In addition to its privacy-focused design, the Elegance Box-Up Series boasts a comprehensive set of high-quality hardware. From Aluminium Powder-coated U-channels, L-channels, and top rail to adjustable legs and auto return hinges, each component is meticulously crafted to ensure durability and long-lasting performance. Super Creations takes pride in providing a restroom solution that not only meets the demands of privacy but also elevates the overall aesthetics, making the Elegance Box-Up Series a top choice for those who value both style and functionality in their restroom spaces.
Providing and fixing toilet cubicle systems of DEBO/STYLAM make and installed by Supercreations in standard dimensions of 900-1200mm width X 1500mm depth X 1980mm height with a door size of 600mm width X 1830mm height with 12mm thickness.
The solid grade Compact Laminate panels made of Phenolic resins under high pressure and temperature having density >1400 kg/m3, including doors, pilasters & intermediate panels, which are resistant to heat, bacteria, chemical, scratch and impact & water immersion through permissible increase on weight will be <0.60~0.8%.
Finished product will be as per approved texture, shade & drawing, detailing and developed according to IS-2046 and EN438 standards and as per fire retardant BS-476/97 standard. The product should have Green Guard Certificate. The toilet cubicle setup shall include necessary
hardware fittings, made out of Nylon Polymide-06, as per manufacturer’s specifications and approved by the engineer.
Hardware fittings consist of:
Aluminium powder-coated U-channels
Aluminium powder-coated top rail
Aluminium powder-coated door stopper channel
Aluminium powder-coated L-channel
Aluminium powder-coated 100mm box
Nylon Polymide lock
Nylon Polymide door knob
Nylon Polymide coat hook
Nylon Polymide gravity hinges
SS 304 screws and PVC wall plugs
Door noise reduction tape
The top fitting arrangement shall comprise of Aluminium powder-coated black top rail, fixed to pilasters. In absence of brick walls, Aluminium powder-coated black L – channel (connected to the top rail) shall be used on the corners of the cubicle. All screws should be of stainless steel (Grade-304). All pilasters shall be supported by Aluminium powder-coated Black Box-up Shoe.
The base of the bottom cladding shall be anchored to the floor with a height of 100mm. The intermediate panel shall be of one continuous panel without any joint. All visible edges shall
be chamfered.
Description
Total height from floor
Width of cubicle
Depth
Divider
height
Pilaster width
Door height
Door width
Top rail height
Bottom gap
Panel thickness
Standard (in mm)
1980
1530
1200
1800
1830
100-300
1800
600
125
150
12
Customised (in mm)
1980 – 2250
1500 – 1830
1200 – 1500
1800 – 2100
1830
100-300
2100
750
125
150
12
