Smart series

Toilet Cubicles /Smart Series

Economical, budget-friendly and very easy to maintain – Elegance series is an efficient model using a sleek aluminium anodized and Nylon Polyamide hardware, apart from standard black. It is also offered in grey, off-white and white finishes

Specification and Requirement: Yes

CAD File on request

Smart Series

Seamless blend of sophistication and budget-friendliness for versatile restroom solutions.

Robust anodized aluminum and stainless steel components ensure long-lasting reliability.

Ideal for IT parks, malls, hospitals; designed to meet diverse design and budget requirements.

Requires minimum 8ft ceiling height
Pilasters are anchored to floor by 100-150mm adjustable legs & at top fixed to top rail of width 50mm
After completion of Wall tiling, floor tiling, ceiling, grouting, painting, electric works & plumbing.
This series can be done when both side walls are available (i.e wall to wall) or only one side wall is available (i.e wall to panel)

Smart Series by Super Creations, a sophisticated solution that seamlessly merges sleek design with budget-friendly practicality for your restroom needs. These cubicles are built to withstand heavy use while maintaining high-performance standards over time. The anodized aluminum framework and stainless steel 316 and 304 accessories ensure durability, offering a reliable and stylish option suitable for various environments, from IT parks to malls and hospitals.

The Smart Series boasts high-performance spring hinges for soft-closing doors, providing both functionality and longevity. Whether you seek a simple and budget-friendly solution or a more bespoke design, the Smart Series is the epitome of excellence in restroom cubicles.

Providing and fixing toilet cubicle systems of DEBO/STYLAM make and installed by Supercreations in standard dimensions of 900-1200mm width X 1500mm depth X 2000mm height with a door size of 600mm width X 1830mm height with 12mm thickness.
The solid grade Compact Laminate panels made of Phenolic resins under high pressure and temperature having density >1400 kg/m3, including doors, pilasters & intermediate panels, which are resistant to heat, bacteria, chemical, scratch and impact & water immersion
through permissible increase on weight will be <0.60~0.8%.

Finished product will be as per approved texture, shade & drawing, detailing and developed according to IS-2046 and EN438 standards and as per fire retardant BS-476/97 standard. The product should have Green Guard Certificate. The toilet cubicle setup shall include necessary hardware fittings, made out of stainless steel (Grade-304 & 316), as per manufacturer’s specifications and approved by the engineer.

Hardware fittings consist of:

Aluminium anodised SS finish U-channels
Aluminium anodised SS finish top rail
Aluminium anodised SS finish door stopper channel
Aluminium anodised SS finish L- channel
SS 316 adjustable foot with 150mm clearance
SS 304 indicator lock
SS 304 door knob
SS 304 coat hook
SS 304 universal hinges
SS 304 screws and PVC wall plugs
Door noise reduction tape

The top fitting arrangement shall comprise of Aluminium Anodized top rail, fixed to pilasters. In the absence of brick walls, Aluminium Anodized L -channel(connected to the
top rail) shall be used at the corners of the cubicle. All screws should be of stainless steel (Grade-304). All pilasters shall be supported by stainless steel (Grade-316) adjustable foot.
The base of the stainless steel adjustable leg shall be anchored to the floor with a clearance height of 150mm. The intermediate panel shall be of one continuous panel without any joint. All visible edges shall be chamfered.
